Apache Spark Questions

✅ Overview 📋

Apache Spark is a unified analytics engine for large-scale data processing.

It provides high-level APIs in Java, Scala, Python, and R, and an optimized engine that supports general computation graphs for data analysis.

Apache Spark is an open-source, distributed processing system designed for big data workloads.

It functions as a unified analytics engine, meaning it can handle various types of data processing tasks within a single framework.

   +------------------------+
   |      Driver Program    |
   |      (SparkContext)    |
   +-----------+------------+
               |
               v
       +-------------------+
       |  Cluster Manager  |
       +---------+---------+
                 |
        -----------------------
        |                     |
        v                     v
 +---------------+     +---------------+
 |   Worker Node |     |   Worker Node |
 |   +---------+ |     |   +---------+ |
 |   | Executor| |     |   | Executor| |
 |   +---------+ |     |   +---------+ |
 |   |  Cache  | |     |   |  Cache  | |
 |   +---------+ |     |   +---------+ |
 |   |  Tasks  | |     |   |  Tasks  | |
 +---------------+     +---------------+

🔷 Core Components 🔍

1️⃣ Driver Program 🚗

The Driver Program is the main control unit of a Spark application that orchestrates the entire execution process.

     Responsibilities:

• SparkContext Creation 🎯 :
         Creates and manages the SparkContext which serves as the entry point for all Spark functionality.
         Coordinates with cluster manager to acquire resources and maintains connection to executors throughout application lifecycle.
• Job Planning 📋 :
         Converts user program into jobs by analyzing RDD lineage and creating directed acyclic graphs (DAG).
         Breaks down complex operations into manageable stages based on data dependencies and shuffle boundaries.
• Task Scheduling ⏰ :
         Schedules tasks across executors based on data locality, resource availability, and workload distribution.
         Optimizes task placement to minimize network overhead and maximize cluster utilization.
• Result Collection 📦 :
         Collects results from executors and aggregates them for final output or further processing.
         Manages data transfer from distributed executors back to the driver for actions like collect() and reduce().
• Fault Recovery 🛡️ :
         Handles executor failures by tracking RDD lineage and recomputing lost partitions on healthy nodes.
         Maintains resilience through automatic retry mechanisms and task rescheduling on alternative executors.

2️⃣ Cluster Manager 🏭

The Cluster Manager is responsible for resource allocation and management across the cluster.

     Overview:

Cluster managers handle resource negotiation, allocation, and monitoring across the distributed cluster.
They provide interfaces for Spark applications to request computing resources and manage the lifecycle of executors on worker nodes.

     Types:

• Standalone Cluster Manager 🏗️ : Spark's built-in cluster manager for simple deployments
• YARN (Yet Another Resource Negotiator) 🐘 : Hadoop's resource manager for enterprise environments
• Apache Mesos ⚖️ : General-purpose cluster manager for diverse workloads
• Kubernetes ☁️ : Container orchestration platform for cloud-native deployments

3️⃣ Worker Nodes 👷‍♂️

Worker Nodes are the compute nodes in the cluster that host and run Spark executors.

• Executor Hosting 🏠 :
         Provides compute resources (CPU cores and memory) to run executor JVM processes.
         Manages multiple executors simultaneously and ensures proper resource isolation between different applications.
• Resource Management 💻 :
         Monitors and allocates system resources including CPU, memory, and disk space to executors.
         Reports resource availability and health status back to the cluster manager for scheduling decisions.

4️⃣ Executors 🏃‍♂️

Executors are JVM processes that run on worker nodes and execute individual tasks.

• Task Execution ⚡ : Runs individual tasks assigned by the driver program and processes data partitions in parallel.
• Data Storage 💾 : Caches RDD partitions in memory or disk based on storage levels and available resources.
• Shuffle Operations 🔀 : Handles data exchange between stages during operations like joins, groupBy, and aggregations.
• Result Reporting 📊 : Reports task completion status, results, and metrics back to the driver program.

5️⃣ SparkContext 🎯

• RDD Creation 🗂️ : Creates RDDs from files, databases, and collections.
• Job Submission 📤 : Converts RDD operations into executable tasks.
• Configuration Management ⚙️ : Manages Spark configuration properties.
• Service Coordination 🤝 : Coordinates Spark services like block manager and web UI.

🔄 Execution Flow

     Job Execution Pipeline:

• Application Submission 📤 : User submits Spark application via spark-submit.
• Resource Request 🤝 : Driver requests resources from cluster manager.
• Executor Launch 🚀 : Cluster manager starts executors on worker nodes.
• Job Processing ⚡ : Driver converts user code into jobs, stages, and tasks.
• Task Distribution 📡 : Tasks distributed based on data locality.
• Result Collection 📊 : Executors return results to driver.

High-Level APIs 🎨

1️⃣ Spark SQL 📊

Provides structured data processing with SQL interface and DataFrame/Dataset APIs.
Includes Catalyst optimizer for query optimization and code generation for high-performance execution.

2️⃣ Spark Streaming 🌊

Enables scalable, fault-tolerant stream processing with micro-batch and continuous processing models.
Integrates with various streaming sources like Kafka, Flume, and TCP sockets.

3️⃣ MLlib 🤖

Machine learning library providing distributed algorithms for classification, regression, clustering, and collaborative filtering.
Includes ML pipelines for feature engineering and model selection workflows.

4️⃣ GraphX 🕸️

Graph processing framework for distributed graph computation and analysis.
Provides graph algorithms like PageRank, connected components, and triangle counting on large-scale graphs.

🔹 Transformation 🧩

A transformation in Spark is a lazy operation that creates a new RDD or DataFrame without executing it immediately.
It only builds the execution plan (lineage) and waits until an action is called.

Examples 📌 : map(), filter(), flatMap(), select()

🔸 Action 🚀

An action is an operation that triggers the actual execution of all previously defined transformations
and returns the final result to the driver or writes it to external storage.

Examples 📌 : count(), show(), collect(), save()

🔁 Key Difference

Transformations build the logical execution plan, while actions execute the plan and produce output.

Lazy Evaluation is a powerful optimization feature in Apache Spark where transformations on RDDs or DataFrames are not executed immediately when they are defined. Instead, Spark builds a logical execution plan and only performs the actual computation when an action (like collect(), count(), show()) is triggered.

✅ Benefits 🎯

• Performance Optimization ⚡ :
         Spark optimizes the logical and physical plans before execution to improve runtime efficiency.
• Avoids Unnecessary Computations ♻️ :
         Only the required transformations are executed, saving CPU and memory resources.
• Pipeline Optimizations 🔧 :
         Enables advanced optimizations like predicate pushdown and projection pruning.

🧠 Simple Insight

Spark first creates a plan, and only works when you ask for the final result.

RDD vs DataFrame vs Dataset in Apache Spark ⚡

🔹 1) RDD (Resilient Distributed Dataset)

     🔸 Definition :

An RDD is an immutable, distributed collection of datasets partitioned across the nodes of a cluster. It supports fault tolerance by enabling recomputation of lost partitions. RDDs are Spark’s fundamental data structure and expose a functional programming API for distributed data processing.

     🔸 Core Concepts :

• Resilient 🔁 : Can be recomputed using lineage if a node fails.
• Distributed 🌐 : Split across a cluster to enable parallelism.
• In-Memory Computing ⚡ : Stores intermediate results in memory for faster access.
• Flexible Creation 🗂️ : Created from HDFS, S3, or parallelized collections.

     🔸 Limitations ❌ :

• ❌ No Catalyst or Tungsten optimizer
• ❌ Not memory-efficient (only on-heap memory)
• ❌ No schema, no native SQL support
• ❌ High serialization overhead
• ❌ Affected heavily by Garbage Collection (GC)

🔹 2) DataFrame 📊

     🔸 Definition :

A DataFrame is a distributed collection of data organized into named columns (similar to a SQL table). It provides high-level APIs and is optimized using the Catalyst Optimizer and Tungsten Engine.

     🔸 Highlights ✨ :

• Table-like structure (similar to SQL, Pandas, R DataFrames)
• Multi-language support (Scala, Python, Java, R)
• Scales from GBs to petabytes on clusters
• Built-in query and memory optimizations

     🔸 Limitations ❌ :

• ❌ Not type-safe (runtime errors)
• ❌ UDFs reduce optimization benefits
• ❌ Harder debugging for schema errors

🔹 3) Dataset 🧩

     🔸 Definition :

Dataset is a strongly-typed distributed collection available in Scala/Java. It combines the benefits of RDDs (type safety) and DataFrames (optimizations). Spark uses Encoders for efficient serialization.

     🔸 Advantages ✅ :

• Type-safe with compile-time checks
• Uses Catalyst & Tungsten optimizations
• Efficient serialization using Encoders
• Supports both functional and SQL-style APIs

     🔸 Limitations ❌ :

• ❌ Not available in PySpark
• ❌ Complex for deeply nested schemas
• ❌ UDFs act as optimization barriers

🔹 4) Common Features (Across All Three) ✅

• ✅ Fault-tolerant
• ✅ Distributed and parallelized
• ✅ Immutable (read-only)
• ✅ Supports lazy evaluation
• ✅ In-memory processing
• ✅ Internally processed as RDDs

🔹 Key Differences ⚡

• API Style 🧠 :
         RDDs & Datasets use OOP/functional API, while DataFrames use SQL-style declarative API.
• How vs What 🤖 :
         RDDs require specifying how to perform tasks; DataFrames/Datasets declare what to do.
• Memory Usage 🧮 :
         RDDs use only on-heap memory, while DataFrames/Datasets use both on-heap and off-heap memory.
• Serialization 📦 :
         RDDs require heavy serialization; DataFrames/Datasets avoid much of it using optimized encoders.
• Garbage Collection 🧹 :
         RDDs suffer from GC overhead, while DataFrames and Datasets significantly reduce GC impact.

✅ Overview 📋

Both repartition() and coalesce() are Apache Spark operations used to change the number of partitions in a DataFrame or RDD, but they work differently and are optimized for different scenarios.

🔷 Key Differences 🔍

Aspect	Repartition	Coalesce
Shuffle	Always triggers full shuffle 🔀	Avoids shuffle when possible ✅
Direction	Can increase or decrease partitions 🔼🔽	Only decreases partitions 🔽
Data Distribution	Even distribution across partitions ⚖️	May result in uneven partitions ⚠️
Performance	Slower due to shuffle overhead 🐌	Faster, minimal data movement 🚀
Use Case	Need even distribution or more partitions	Efficiently reduce partitions
Network I/O	High network overhead 📡	Minimal network overhead 📉

🔷 When to Use Each 💡

     ✅ Use Repartition When :

• Increasing partition count for better parallelism ⚡
• Need even data distribution across partitions ⚖️
• Preparing for downstream operations that benefit from uniform partitions
• Data is heavily skewed and needs redistribution 📊

     Example 💻 :

df = spark.read.parquet("input.parquet")

repartitioned_df = df.repartition(10)        # 10 partitions with even distribution

repartitioned_by_col = df.repartition("customer_id")   # Partition by column

     ✅ Use Coalesce When :

• Reducing partition count to avoid small files 📦
• Minimizing shuffle overhead is a priority ✅
• Final stage before writing to reduce output files 📝
• Data distribution is already acceptable ⚖️

     Example 💻 :

# Coalesce example

coalesced_df = df.coalesce(5)    # Reduce to 5 partitions, no shuffle

✅ What is cache()? 🚀

A shortcut to store a DataFrame in memory for faster reuse.

• Uses the default storage level: MEMORY_AND_DISK 💾
• If data fits in memory, it stays there; otherwise Spark spills to disk 🧠➡️💽
• Ideal for frequently accessed data in iterative jobs 🔁

✅ What is persist()? 🧩

Similar to cache(), but gives you full control over where and how the data is stored.

• You can choose different storage levels (memory, disk, serialized formats) ⚙️
• Useful when datasets are large or memory is limited 📊

🔹 Storage Levels in persist() 💾

• MEMORY_ONLY ⚡: Fastest, but recomputes if memory is insufficient
• MEMORY_AND_DISK ✅: Safe default, spills to disk when memory is full
• MEMORY_ONLY_SER 🧊: Stores serialized (compressed) data in memory
• MEMORY_AND_DISK_SER 💽: Serialized memory + disk backup
• DISK_ONLY 🐢: Stores only on disk (slower but safe)
• OFF_HEAP 🧠: Uses external memory (advanced use case)

🟢 When to Use cache()? ✅

• Quick caching without tuning ⚡
• Data fits in memory or disk fallback is acceptable 💡
• DataFrame reused multiple times in a pipeline 🔁

🟡 When to Use persist()? 🎯

• You need control over storage strategy ⚙️
• Large datasets that don't fit fully in memory 📦
• Memory-constrained environments to avoid OOM errors ⚠️
• Performance tuning experiments 🔬

💻 Code Examples 👇

df = spark.read.csv("data.csv", header=True)

# Cache the DataFrame in memory (with disk fallback)
df.cache()

from pyspark import StorageLevel

df = spark.read.csv("data.csv", header=True)

# Persist using memory-only storage (won’t use disk)
df.persist(StorageLevel.MEMORY_ONLY)

🔷 Accumulators

✅ What is an Accumulator?

A write-only shared variable used to perform aggregations or counters across Spark tasks.

Useful for counting events like errors, nulls, or processed records.

Only the driver can read its value; executors can only update it.

🚫 Important:

You should not use an accumulator to influence data transformation logic — it's not guaranteed to update exactly once per record (especially with lazy evaluation and task retries).

\# Create an accumulatorerror_count = sc.accumulator(0)

---

🔷 Broadcast Variables

✅ What is a Broadcast Variable?

A read-only shared variable cached on all executors.

Used to efficiently share large lookup data (e.g., dictionaries or reference tables) across all tasks.

Prevents sending a copy with each task, which saves network traffic and memory.

broadcast_var = sc.broadcast(lookup_dict)

✅ What is Lineage?

Lineage is the history or recipe of how a DataFrame or RDD was created.

It's a logical chain of transformations applied to data (like map, filter, join, etc.).

Spark tracks lineage to recompute lost data if a partition fails (fault tolerance).

🧠 Example:

 rdd1 = sc.textFile("file.txt") rdd2 = rdd1.map(lambda x: x.split()) rdd3 = rdd2.filter(lambda x: len(x) > 3) The lineage of rdd3 is: → file.txt → map() → filter()

📌 Use:

Spark uses lineage info to recompute data without needing to persist/copy data. Essential for fault recovery.

---

🔶 DAG (Directed Acyclic Graph)

✅ What is a DAG?

A DAG is a graph of stages and tasks that Spark builds to execute your job.

It includes:

• All stages of transformations.
• Their execution order.
• Information about shuffles, dependencies, and task boundaries.

🧠 Example:

If your job has map → groupBy → count, Spark breaks it into stages and tasks with dependencies — this forms a DAG.

Deploy modes decide where the Spark Driver runs and how your application is executed.

✅ 1) Client Mode 🧑‍💻

• Driver runs on your local machine (where spark-submit is executed) 💻
• Executors run on the cluster (YARN, Kubernetes, Standalone, etc.) 🖥️
• Application logs and output are shown directly in your terminal 📟
• Used for: Development, notebooks, testing, and debugging 🧪

✅ 2) Cluster Mode 🏗️

• Driver runs inside the cluster (e.g., YARN container or Kubernetes Pod) ☁️
• You can disconnect after submission — Spark job continues to run independently 🔄
• Logs are stored in cluster management tools (YARN logs / Kubernetes pod logs) 📦
• Used for: Production workloads, scheduled jobs, and automation 🤖

🔑 Key Difference

In Client Mode, the driver lives on your machine. In Cluster Mode, the driver lives inside the cluster.

These modes define how and where Spark runs on different cluster managers.

✅ 1) Standalone Mode 🧱

     What it is:

• Spark’s built-in cluster manager ⚙️
• Does not require Hadoop or any external system 🚫🐘
• You manually start a Master and multiple Worker nodes 🖥️

     When to use ✅:

• Small to medium Spark clusters
• Simple setup without Hadoop or Kubernetes

✅ 2) YARN Mode 🐘

     What it is:

• Spark runs on top of Hadoop YARN as the cluster manager 🏗️
• Very common in enterprise Hadoop environments 🏢
• Supports both client mode and cluster mode 🔁

     When to use ✅:

• When working in a Hadoop ecosystem
• When Spark needs to share resources with Hive, HDFS, etc.

✅ 3) Kubernetes Mode ☸️

     What it is:

• Spark runs natively on a Kubernetes cluster ☁️
• Uses Pods for Driver and Executors 🧊
• Supports autoscaling and containerized execution 📦

     When to use ✅:

• Cloud-native infrastructure (AWS EKS, GCP GKE, AKS)
• Docker-based deployments with strong resource isolation 🐳

🔑 Quick Summary

Standalone → Simple, Spark-only cluster
YARN → Best inside Hadoop ecosystem
Kubernetes → Best for cloud-native, container-based setups

✅ Quick Difference

🔹 groupByKey: Groups all values for a key first, then aggregates (heavy shuffle).
🔹 reduceByKey: Aggregates values during shuffle, reducing data early and improving efficiency.

✅ 1) reduceByKey 🔁

     Syntax:

reduceByKey(func, [numTasks])

     How it works:

• Performs local aggregation within each partition 🧮
• Combines values before shuffle using a combiner ⚙️
• Only reduced results are shuffled across the network 📡
• Much less data transfer compared to groupByKey 🚀

     Best use case ✅:

When you want sum, min, max, avg or other aggregations.

✅ 2) groupByKey 🧺

     Syntax:

groupByKey([numTasks])

     How it works:

• No local reduction happens ❌
• All raw values are shuffled across the network 📦
• Values are grouped only after shuffle on destination partition
• High memory usage on worker nodes 🔥
• Can cause OutOfMemory (OOM) errors ⚠️

     Best use case ✅:

When you want to retain all values as a list for each key.

✅ Semantic Difference 🧠

• groupByKey: Returns (key, Iterable[values]) → full list of values 📋
• reduceByKey: Returns (key, reducedValue) → single aggregated value 🎯

✅ Performance ⏱️

• groupByKey: More network traffic + more memory usage ❌
• reduceByKey: Less shuffle + better performance ✅

✅ Example 🧪

# Sample key-value pair RDD
data = [("A", 1), ("B", 2), ("A", 3), ("B", 4), ("C", 5)]

# Using groupByKey
grouped = rdd.groupByKey()
# Result: [("A", [1, 3]), ("B", [2, 4]), ("C", [5])]

# Using reduceByKey
reduced = rdd.reduceByKey(lambda x, y: x + y)
# Result: [("A", 4), ("B", 6), ("C", 5)]

⚡ Interview Tip:

Use reduceByKey for aggregation and performance.
Use groupByKey only when you truly need the full list of values.

✅ What is Partitioning? 🧩

Partitioning divides a table into separate directories based on column values. Each partition represents a subset of data stored in its own directory structure.

     📁 Partitioning Structure

/warehouse/sales_table/
├── year=2023/month=01/
│   ├── file1.parquet
│   └── file2.parquet
├── year=2023/month=02/
│   ├── file1.parquet
│   └── file2.parquet
└── year=2024/month=01/
    ├── file1.parquet
    └── file2.parquet

     ✅ Advantages of Partitioning

• Partition Pruning 🚀 — Skips irrelevant partitions
• Parallel Processing ⚡ — Independent processing per partition
• Data Locality 📦 — Related data stays together
• Easy Data Management 🛠️ — Add or drop partitions easily

     ❌ Disadvantages of Partitioning

• Small File Problem 🧨 — High-cardinality columns create many small files
• Metadata Overhead 🧾 — Too many partitions increase metadata load
• Uneven Distribution ⚖️ — Skewed partition sizes
• Inefficient Queries 🔍 — Only effective when filtering on partition columns

---

✅ What is Bucketing? 🪣

Bucketing distributes data into a fixed number of buckets using a hash function applied to specified columns.

     🗃️ Bucketing Structure

/warehouse/sales_table/
├── bucket_00000.parquet
├── bucket_00001.parquet
├── bucket_00002.parquet
├── bucket_00003.parquet
└── ...

     ✅ Advantages of Bucketing

• Fixed File Count 📏 — Prevents small file problem
• Even Distribution ⚙️ — Hashing spreads data uniformly
• Join Optimization 🔗 — Enables bucket-map joins
• Efficient Sampling 🎯 — Read specific buckets
• Reduced Shuffling 🔄 — Minimizes data movement

     ❌ Disadvantages of Bucketing

• No Partition Pruning ❌ — Cannot skip buckets
• Hash Collisions ⚠️ — Can cause uneven distribution
• Bucket Count Choice 🎲 — Requires good planning
• Fixed Structure 🔒 — Bucket count cannot change easily

---

✅ Key Differences 📊

Aspect	Partitioning	Bucketing
Data Organization	Directory-based	Hash-based buckets
File Count	Variable	Fixed
Query Pruning	Supported ✅	Not Supported ❌
Data Distribution	Can be skewed	Generally uniform
Small File Problem	Prone ❌	Prevented ✅
Join Performance	Standard joins	Optimized bucket joins 🚀
Metadata Overhead	High with many partitions	Low (fixed metadata)

✅ Bucket Count Guidelines 📏 (Important)

• Use powers of 2 or multiples of core count 🧮
• Target file size of 128MB – 1GB 📦
• Use same bucket count on join tables 🔗
• Plan for data growth 📈

✅ Conclusion 🧠

Use Partitioning for time-series and filter-heavy queries.
Use Bucketing for high-cardinality joins and uniform distribution needs.
Use a Hybrid approach when you need both pruning and join optimization.

✅ What is a Shuffle Hash Join?

A Shuffle Hash Join is a join strategy used in Spark when two large tables are joined and neither can fit entirely in memory (unlike Broadcast Join).

Spark shuffles both datasets across the cluster by the join key, then performs a hash-based join inside each partition.

🧠 How It Works (Step-by-Step)

• Shuffle 🔁 : Both DataFrames are redistributed so that rows with the same join key land in the same partition.
• Build Phase 🧱 : Spark builds an in-memory hash table using the smaller dataset (if known).
• Probe Phase 🔎 : Spark scans the larger dataset and looks up matches inside the hash table.
• Output ✅ : Matching rows are combined and returned.

🔁 When is it Used?

• When Broadcast Join is not possible 📡
• When both tables are too large for memory 💾
• When Spark cannot determine a clearly smaller table 🤷‍♂️

📊 Shuffle Hash Join Process

     Step 1: Shuffle Phase 🔀

Node 1 receives:
  Orders:    (101, order_data)
  Customers: (101, customer_data)

Node 2 receives:
  Orders:    (102, order_data)
  Customers: (102, customer_data)

Node 3 receives:
  Orders:    (103, order_data)
  Customers: (103, customer_data)

     Step 2: Hash Join Phase 🧮

Node 1:
  Hash Table:
    {101: ("Alice", "NYC")}

  Probe:
    Orders: (1, 101, 250) → Match found ✅

  Result:
    (1, 101, 250, "Alice", "NYC")

⚠️ Trade-offs

Pros ✅	Cons ❌
Works well for large tables	Expensive shuffle operation
Scales with cluster size	Requires high memory for hash map
Supports high parallelism	Performance suffers with skewed data

📝 Real-World Notes

• Spark uses ShuffledHashJoin when one side is smaller, but not small enough to broadcast 📦
• Both datasets are shuffled, which makes this join expensive ⚠️

✅ How it works ⚙️

• Smaller table is broadcast to all executors 📦
• No shuffle is required for the larger table 🚫🔀
• Each executor performs the join locally 🧠

✅ When is it used? ⏱️

• One table is smaller than spark.sql.autoBroadcastJoinThreshold (default ~10MB) 📏
• Spark automatically selects it for small dimension tables 🤖

🧪 Example

-- Users: 5MB, Orders: 10GB
SELECT *
FROM orders o
JOIN users u
  ON o.user_id = u.id;

🔁 Process Flow

• 1️⃣ Broadcast the Users table to all executors 📤
• 2️⃣ Each executor builds a local hash table 🧱
• 3️⃣ Orders table stays partitioned (no shuffle) 📦
• 4️⃣ Local join executed inside each executor ✅

✅ Pros ⭐

• No shuffle required 🚀
• Very fast for small dimension tables ⚡
• Perfect for star schema joins 🌟

❌ Cons ⚠️

• Limited by broadcast size threshold 📏
• Consumes driver and executor memory 🧠

✅ How it works ⚙️

• Both tables are shuffled by the join key 🔀
• Each partition is sorted by the join key 🔤
• A merge-sort algorithm is used to join sorted partitions 🔗
• This is the default join strategy when others don’t apply 🤖

✅ When is it used? ⏱️

• Both tables are large 📊
• Equi-joins with sortable keys 🔑
• When broadcast and hash joins are not suitable 🚫

🧪 Example

-- Table A: 5GB, Table B: 8GB
SELECT *
FROM large_table_a a
JOIN large_table_b b
  ON a.category = b.category;

🔁 Process Flow

• 1️⃣ Shuffle both tables by join key 🔀
• 2️⃣ Sort partitions by join key 🔤
• 3️⃣ Merge sorted partitions using two-pointer technique 🧭
• 4️⃣ Stream through both datasets simultaneously 🌊

✅ Pros ⭐

• Works with very large tables ✅
• Memory efficient due to streaming nature 💾
• Handles duplicate keys well 🔁

❌ Cons ⚠️

• Requires shuffle for both tables 🔀
• Sorting overhead adds latency 🐢
• Slower than hash-based joins ⏳

✅ Join Selection Logic 🧠

Is smaller table < 10MB?
├─ ✅ YES → 📢 Broadcast Join
└─ ❌ NO → Is smaller table < 64MB and fits in memory?
    ├─ ✅ YES → 🔀 Shuffle Hash Join
    └─ ❌ NO → 🔁 Sort Merge Join

📊 Performance Comparison Table

Join Type	Shuffle Required	Memory Usage	Best For
📢 Broadcast Join	One side only	High (broadcast)	Small dimension tables
🔀 Shuffle Hash Join	Both sides	Medium (hash table)	Medium tables with size difference
🔁 Sort Merge Join	Both sides	Low (streaming)	Large tables of similar size

🎯 Key Interview Points

• 📢 Broadcast Join is the fastest but limited by table size.
• 🔀 Shuffle Hash Join is the middle-ground and requires enough executor memory.
• 🔁 Sort Merge Join works in most cases but has sorting overhead.
• 🤖 Spark automatically selects join strategy based on table statistics.
• 🧩 You can force a strategy using hints: /*+ BROADCAST(table) */

Dynamic Resource Allocation (DRA) allows Spark to automatically adjust the number of executors at runtime based on workload.

✅ Why Use Dynamic Resource Allocation?

• 📈 Scales up executors when workload increases
• 📉 Scales down executors when they are idle
• 💰 Optimizes overall cluster resource usage

🧠 How It Works

• Monitors number of pending tasks
• Tracks executor idle time
• Adds or removes executors automatically
• Works with YARN, Kubernetes, or Standalone cluster manager

⚙️ Key Configurations

spark.dynamicAllocation.enabled              = true
spark.dynamicAllocation.minExecutors         = 2
spark.dynamicAllocation.initialExecutors     = 4
spark.dynamicAllocation.maxExecutors         = 10
spark.dynamicAllocation.executorIdleTimeout  = 60s

🧪 Example spark-submit

spark-submit \
  --conf spark.dynamicAllocation.enabled=true \
  --conf spark.dynamicAllocation.minExecutors=2 \
  --conf spark.dynamicAllocation.maxExecutors=8 \
  --conf spark.dynamicAllocation.executorIdleTimeout=60 \
  your_script.py

🛠 Required Setting

spark.shuffle.service.enabled=true

✅ Benefits

• 💸 Frees unused resources automatically
• ⚡ Adapts to workload changes in real time
• 🤖 Removes need for manual executor tuning

⚠️ Why Static Allocation Is Bad

• Wastes resources when executors stay idle
• Can cause slow jobs when executors are insufficient
• Cannot adapt to workload spikes

🎯 Interview Key Points

• Spark scales executors based on pending tasks
• Requires external shuffle service to work correctly
• Most useful for long-running and streaming jobs

⚡ Adaptive Query Execution (AQE) in Spark

Adaptive Query Execution (AQE) is a dynamic optimization feature in Spark SQL (Spark 3.x+) that changes the execution plan at runtime based on real data statistics.

🎯 Why AQE Is Needed

• Traditional Spark plans are built at compile time using limited statistics
• Real-world data contains skew, unknown sizes, and uneven distributions
• AQE adapts the plan during execution based on actual runtime metrics

⚙️ Key Features of AQE

• 🔄 Dynamic Join Strategy Selection (can switch Sort-Merge → Broadcast Join)
• ⚖️ Skew Join Handling by splitting skewed partitions
• 📦 Dynamic Shuffle Partition Coalescing to reduce small tasks
• ♻️ Local Shuffle Reader for efficient shuffle reuse

🌍 Real-World Use Case

In a production workload joining ship activity with weather data, heavy port skew caused some tasks to run 10x slower. After enabling AQE and skew join handling, execution time improved by over 40% and stabilized job performance.

🛠 How to Enable AQE

spark.sql.adaptive.enabled=true
spark.sql.adaptive.coalescePartitions.enabled=true
spark.sql.adaptive.skewJoin.enabled=true
spark.sql.adaptive.localShuffleReader.enabled=true

📌 Configuration Explanation

spark.sql.adaptive.enabled                    → Enables AQE
spark.sql.adaptive.skewJoin.enabled           → Handles skewed joins
spark.sql.adaptive.coalescePartitions.enabled → Merges small shuffle partitions
spark.sql.adaptive.localShuffleReader.enabled → Improves shuffle reuse

⚠️ When AQE May Not Help

• Cluster is CPU or disk I/O bottlenecked
• Data is already perfectly partitioned
• Manual hints may override AQE decisions

✅ Best Practices

• Enable AQE by default for batch workloads
• Monitor decisions in Spark UI under "Adaptive Spark Plan"
• Combine with partitioning and Delta Lake Z-Ordering

🏁 Summary

AQE helps Spark dynamically optimize execution at runtime, improving performance, cost efficiency, and reliability without heavy manual tuning.

Off-heap memory in Apache Spark refers to memory allocated outside the Java Virtual Machine (JVM) heap. This memory is manually managed by Spark and is not controlled by the Garbage Collector (GC), helping reduce GC overhead and improve performance.

🧠 1. What is Off-Heap Memory?

• Allocated outside the JVM heap using native methods
• Not managed by the Java Garbage Collector
• Explicitly controlled and released by Spark
• Ideal for caching, shuffle buffers, and intermediate state management

✅ 2. Why Use Off-Heap Memory?

• 🗑️ Reduced GC overhead for large datasets
• ⚡ Faster binary serialization and direct memory access
• 📦 Compact memory layouts with fixed-length storage
• 🚀 Better memory utilization with low object overhead
• 📥 Handles large memory buffers efficiently

🛠️ 3. How to Enable Off-Heap Memory

spark.memory.offHeap.enabled=true
spark.memory.offHeap.size=4g

You can configure this via:

• spark-submit --conf
• spark-defaults.conf
• Notebook / Databricks session configs

⚙️ 4. Components That Use Off-Heap Memory

4.1 Tungsten Execution Engine 🔥

• Uses off-heap for rows, sorts, and aggregations
• Uses UnsafeRow and UnsafeMemory
• Reduces object creation and GC load

4.2 Spark SQL Caching 💾

• Serialized caching can leverage off-heap storage

4.3 Broadcast Variables 📡

• Large broadcast tables can live off-heap

4.4 Shuffle & Sort Buffers 🔀

• Uses off-heap during shuffle, spill, and external sorting

⚖️ 5. Heap vs Off-Heap Memory

Heap Memory       → JVM Garbage Collected, Object-Based, Higher GC cost
Off-Heap Memory   → Manually Managed by Spark, Binary Format, Low GC cost

⚠️ 6. Limitations & Considerations

• Manual memory release risks native memory leaks
• Harder to debug than heap-based memory
• Spark UI does not directly show off-heap usage
• Off-heap size must be pre-allocated

✅ 7. Best Practices

• Tune off-heap size based on executor memory layout
• Enable compressed in-memory columnar storage
• Use OS-level tools like top, htop, jcmd for monitoring
• Combine with dynamic allocation and proper spill configs

🏁 8. Summary

Off-heap memory helps Spark avoid GC pauses, improve throughput, and handle large datasets efficiently. It is best suited for shuffle-heavy workloads, caching use cases, and large-scale Spark SQL processing when sized and monitored correctly.

🔹 1. What is SparkContext?

SparkContext is the primary entry point to Spark’s core functionality in Apache Spark 1.x. It allows applications to connect to a cluster and perform distributed processing using RDDs (Resilient Distributed Datasets).

     Key Responsibilities:

• Cluster Connection 🌐 : Initializes connection to YARN, Mesos, or Standalone cluster manager
• Job Scheduling 🗓️ : Manages job scheduling and task distribution across executors
• RDD Creation 📦 : Creates RDDs from files or in-memory collections
• Configuration Access ⚙️ : Reads Spark configuration from SparkConf
• Hadoop Integration 🐘 : Works with HDFS and Hadoop-compatible file systems

val conf = new SparkConf().setAppName("MyApp").setMaster("local[*]")
val sc = new SparkContext(conf)

     Limitations:

• ❌ No built-in SQL, Hive, or DataFrame support
• ❌ Requires separate SQLContext or HiveContext

🔹 2. What is SparkSession?

SparkSession, introduced in Spark 2.0, is the unified entry point for working with Spark SQL, RDDs, DataFrames, and Datasets. It merged all older contexts into a single, simplified API.

     Key Benefits:

• Unified API Access 🧩 : Supports SQL, DataFrame, Dataset, and RDD APIs
• Simplified Initialization 🧱 : Uses builder pattern for cleaner configuration
• SQL & Hive Support 🧮 : Directly runs SQL and Hive queries
• Catalog Access 📚 : Query metadata, tables, and databases
• Internal SparkContext 🔗 : Accessible via spark.sparkContext

val spark = SparkSession.builder()
  .appName("MyApp")
  .master("local[*]")
  .enableHiveSupport()
  .getOrCreate()

🔹 3. Why was SparkSession Introduced?

     Reasons:

• Unified API 🧠 : Combines SparkContext, SQLContext, and HiveContext
• Ease of Use ✨ : Reduces setup complexity
• Better Integration 🔗 : Built-in Spark SQL and Hive metastore support
• Future-Proof 🚀 : Aligns with Spark’s structured processing roadmap
• Cleaner Syntax 🧼 : Fluent, readable configuration style

📝 Quick Summary

• SparkContext 🏗️ : Low-level engine mainly for RDD-based processing
• SparkSession 🧩 : Modern unified entry point for all Spark APIs

📘 Data Skewness in Apache Spark

❓ What is Data Skew?

Data skew occurs when data is unevenly distributed across partitions — meaning some partitions hold a much larger volume of data than others. This creates slow-running tasks and poor cluster efficiency.

⚠️ Why It Matters

In Spark, wide operations like groupByKey, join, and reduceByKey involve shuffles. When certain keys appear too frequently, one partition becomes overloaded, while other executors stay idle — leading to straggler tasks and stage delays.

🛠️ How to Fix Data Skew

Strategy	Description
Salting 🧂	Append random suffixes to skewed keys to distribute data across partitions
Broadcast Join 📡	Broadcast small tables to avoid expensive shuffles
Custom Partitioning ⚙️	Implement custom partitioners for better load balancing
Skew Join Handling (Spark 3+) 🤖	Enable spark.sql.adaptive.skewJoin.enabled = true to auto-handle skew

✅ Best Practices

• Prefer reduceByKey or aggregateByKey over groupByKey ⚡
• Monitor Spark UI for long-running stages and straggler tasks 📊
• Enable AQE (Adaptive Query Execution) in Spark 3.x for automatic optimizations 🚀

❓ What is Salting?

Salting is a technique used to handle data skew in Apache Spark by adding randomness to highly frequent keys. This spreads records more evenly across partitions during join, groupBy, and reduceByKey operations.

🔧 Salting for Aggregation (groupBy / reduceByKey)

✅ Goal

Break “hot keys” into multiple pseudo-keys using random salts so workload is distributed across executors.

🔄 Steps

• Add a random salt column 🎲
• Create a salted key by combining original key + salt 🔗
• Aggregate using salted keys 📊
• Remove salt and re-aggregate to get final results ✅

✅ Code Example

from pyspark.sql import SparkSession
from pyspark.sql.functions import col, rand, concat, split

spark = SparkSession.builder.appName("SaltingExample").getOrCreate()

data = [("A", 100)] * 1000000 + [("B", 200)] * 1000
df = spark.createDataFrame(data, ["product", "amount"])

df_salted = df.withColumn("salt", (rand() * 10).cast("int"))

df_salted = df_salted.withColumn("product_salted", concat(col("product"), col("salt")))

intermediate = df_salted.groupBy("product_salted").sum("amount")

result = intermediate.withColumn("product", split(col("product_salted"), "_")[0]) \
                     .groupBy("product").sum("sum(amount)")

result.show()

🔁 Salting for Join Operations

✅ Goal

Replicate the small table with multiple salts so it matches salted keys of the large skewed table.

✅ Join Salting Code Example

from pyspark.sql.functions import explode, array, lit

large = df.withColumn("salt", (rand() * 5).cast("int"))
large = large.withColumn("product_salted", concat(col("product"), col("salt")))

small_data = [("A", "Type1"), ("B", "Type2")]
small = spark.createDataFrame(small_data, ["product", "type"])

salt_range = array([lit(i) for i in range(5)])
small_expanded = small.withColumn("salt", explode(salt_range))
small_expanded = small_expanded.withColumn("product_salted", concat(col("product"), col("salt")))

joined = large.join(small_expanded, on="product_salted", how="inner")

🚫 When Not to Use Salting

• If data skew is mild or temporary ⚠️
• If AQE with spark.sql.adaptive.skewJoin.enabled = true is enabled 🤖
• If a Broadcast Join is possible 📡

📘 Spark Small File Problem

🔍 What Are Small Files?

• Files smaller than the HDFS block size (typically 128MB)
• Spark processes each file as a separate task, so many small files → many tasks → high overhead

📏 What Counts as “Small”?

File Size	Impact
< 1MB	Very severe performance issues ❌
1MB – 32MB	Noticeable performance hit ⚠️
32MB – 128MB	Acceptable ✅
128MB – 1GB	Optimal for Spark 🚀

⚠️ Why Are Small Files a Problem?

• Task Overhead ⏱️
  One task per file → more scheduling time → slower jobs
• Metadata Overhead 🧠
  HDFS/Spark must track each file → higher memory usage
• Resource Underutilization ⚙️
  Tiny tasks finish fast and waste CPU/memory

💥 Common Causes

• Frequent writes with small DataFrames
• High-cardinality partition columns (e.g., user_id)
• Micro-batch streaming jobs

🧪 Example Problem

# Bad practice – creates small files
df = spark.read.json("tiny_input.json")   # ~5MB
df.write.parquet("output/")

✅ Solutions to the Small File Problem

1️⃣ Coalesce or Repartition

# Combine small partitions into fewer large ones
df.coalesce(1).write.parquet("output/")

# Use repartition() when you want even distribution (causes shuffle)

2️⃣ Set Target File Size

# Target ~128MB file size
spark.conf.set("spark.sql.files.maxPartitionBytes", 134217728)

3️⃣ Use Efficient File Formats

df.write.format("parquet").save("output/")

• Avoid JSON/CSV for analytics workloads ❌
• Prefer Parquet/ORC for performance ✅

4️⃣ Enable Compression

spark.conf.set("spark.sql.parquet.compression.codec", "snappy")

5️⃣ Smart Partitioning

• Avoid high-cardinality columns like user_id, transaction_id ❌
• Use low-cardinality columns like year, month, region ✅

🏁 Best Practices Summary

• 🎯 Target file size: 128MB – 1GB
• ✅ Minimum acceptable: 32MB
• 🚫 Avoid very small files (<1MB)
• 📂 Use coalesce(), Parquet, compression, and smart partitioning

❓ What is Serialization?

Serialization in Spark is the process of converting objects into a byte-stream format so they can be:
• Transferred across the network
• Stored in memory or disk
• Reconstructed later when needed

Since Spark is distributed, both data and code (closures) must move from the Driver to Executors.

📍 Where Spark Uses Serialization

Component	Purpose
RDD / DataFrame Shuffle	Send intermediate data across executors
Broadcast Variables	Distribute large read-only variables efficiently
Accumulators	Track global metrics
Caching	Store intermediate results in serialized form
Closures	Send function logic from Driver to Executors

🚀 Built-in Spark Serializers

Serializer	Description
Java Serializer	Default. Slower and creates large objects.
Kryo Serializer	Faster and more compact (requires class registration).

⚙️ Enable Kryo (Recommended)

spark.serializer = org.apache.spark.serializer.KryoSerializer
spark.kryo.registrationRequired = true

🔥 Why Serialization Matters for Performance

Concern	Explanation
Speed ⚡	Java serialization is slow. Kryo can be 10x–100x faster.
Size 📦	Serialized objects consume memory. Kryo produces smaller payloads.
GC Pressure 🧹	Large serialized objects increase garbage collection overhead.
Shuffle & Disk IO 💾	Compact serialization speeds up shuffle and reduces disk spill.

✅ Interview Tip

Always mention that Kryo is preferred in production due to better performance and lower memory usage.

🚨 Apache Spark Out of Memory (OOM) Issues: Causes and Solutions

📌 What is an OOM Error in Spark?

OOM (Out Of Memory) errors in Apache Spark happen when a task or executor exceeds the memory limit allocated to it, leading to failure. These issues can severely impact job performance or cause job failure.

🔍 Root Causes of OOM in Spark

1️⃣ Large Data Volume
    Processing more data than available memory.
    Joining large datasets without adequate partitioning.

2️⃣ Skewed Data
    Uneven distribution of data causes some partitions to be much larger than others.
    Leads to few tasks requiring more memory than allocated.

3️⃣ Improper Partitioning
    Too few partitions → large partitions → memory pressure.
    Too many partitions → excessive task scheduling overhead.

4️⃣ Large Shuffles
    Wide transformations (e.g., groupByKey, join, reduceByKey) can cause massive shuffles requiring memory for sorting, buffering, and storing shuffle files.

5️⃣ Improper Caching
    Caching large datasets in memory without persist(StorageLevel.MEMORY_AND_DISK) fallback.
    Repeated caching without unpersisting old data.

6️⃣ Memory Configuration Mismanagement
    Low executor/driver memory configuration.
    Spark's memory management (storage vs execution memory) poorly tuned.

7️⃣ Improper Use of Collect or Broadcast
    collect() brings all data to the driver → OOM on driver.
    Broadcasting very large variables → OOM on executors.

🛠️ Solutions and Best Practices

✅ General Memory Management

    spark.executor.memory → Amount of memory allocated to each executor
    spark.driver.memory → Memory allocated to the driver
    spark.memory.fraction → Fraction of memory for execution and storage (default 0.6)
    spark.memory.storageFraction → Fraction of memory reserved for storage

Use Spark UI to monitor memory usage.

Increase executor and driver memory based on workload:

--executor-memory 8g
--driver-memory 4g


✅ Data Skew Mitigation

    Salting technique: Add random prefix to keys before shuffle operations.
    Repartitioning: Use repartition() or coalesce() to balance data distribution.
    Avoid groupByKey; prefer reduceByKey or aggregateByKey.

✅ Optimize Shuffles

Tune these shuffle configurations:

spark.shuffle.compress=true
spark.shuffle.spill.compress=true
spark.shuffle.file.buffer=64k
spark.reducer.maxSizeInFlight=48m


✅ Cache Carefully

    Use .persist(StorageLevel.MEMORY_AND_DISK) instead of .cache() when unsure if data fits in memory.
    Explicitly call .unpersist() when cached data is no longer needed.

✅ Partitioning Strategy

    Aim for ~100–200 MB per partition for optimal performance.
    Tune number of partitions:

spark.sql.shuffle.partitions=200


✅ Avoid Large Collect/Broadcast

    Avoid using .collect() unless data is small enough to fit in driver memory.
    Prefer take(n) for sampling.
    Avoid broadcasting large datasets.

🧠 1. Executor Memory OOM

Scenario: Spark throws java.lang.OutOfMemoryError: Java heap space
Where it happens: Inside the executors when tasks run out of heap memory.

Example:

val data = sc.textFile("large_file.csv")
val grouped = data.map(_.split(",")(0)).groupByKey().collect()


Fixes:
    Avoid groupByKey, use reduceByKey or aggregateByKey.
    Increase executor memory: --executor-memory 8G
    Repartition with smaller partitions: df.repartition(200)
    Enable spill to disk (default is enabled for shuffles).

🧠 2. Driver Memory OOM

Example:

val bigDF = spark.read.parquet("huge_table")
val localList = bigDF.collect()


Fixes:
    Avoid .collect(), prefer .show() or .take(10).
    Increase driver memory: --driver-memory 4G
    Use .foreach() instead of pulling data to driver.

🧠 3. Shuffle Memory OOM

Example:

val df = bigDF1.join(bigDF2, "key")


Fixes:
    Enable adaptive query execution (AQE): spark.sql.adaptive.enabled=true
    Use skew join handling: spark.sql.adaptive.skewJoin.enabled=true
    Increase spark.shuffle.memoryFraction
    Use salting or bucketing for skewed keys.

🧠 4. Broadcast Join OOM

Example:

spark.conf.set("spark.sql.autoBroadcastJoinThreshold", 100 * 1024 * 1024)
val result = bigDF.join(smallDF, Seq("id"))


Fixes:
    Reduce spark.sql.autoBroadcastJoinThreshold (e.g. 10MB).
    Use hint("MERGE") to force shuffle join.
    Partition both tables before join to avoid broadcasting.

🧠 5. Caching OOM

Example:

val df = spark.read.parquet("huge_file")
df.cache()
df.count()


Fixes:
    Use persist(StorageLevel.MEMORY_AND_DISK)
    Unpersist unused cached data: df.unpersist()
    Compress in-memory storage: spark.rdd.compress=true

🧠 6. Too Many Partitions (Task OOM)

Example:

val df = spark.read.json("s3://bucket/small_files/*")
df.repartition(10000)


Fixes:
    Use coalesce() or sensible repartition() count.
    Use file compaction (autocompaction or OPTIMIZE in Delta).
    Avoid explode on huge arrays without filtering.

🔹 Spark Unified Memory

Spark Unified Memory

👉 Short understanding:

Spark Unified Memory is the pool used together by Storage & Execution memory. Earlier Spark had separate pools, but now they dynamically borrow from each other. This allows Spark to utilize memory efficiently and avoid OOM issues.

📊 Spark Memory Architecture Diagram

[ Executor ]
     |
     ├──Reserved (300MB)  ← fixed
     |
     └──Spark Memory
            |
            ├──Storage (50%)
            |
            └──Execution (50%)


 ┌───────────────────────────────┐
 │           Executor            │
 │                               │
 │  ┌─────────────────────────┐  │
 │  │      JVM Heap Memory    │  │
 │  └─────────────────────────┘  │
 │                               │
 │  ┌─────────────────────────┐  │
 │  │     Overhead Memory     │  │
 │  └─────────────────────────┘  │
 │                               │
 │ spark.executor.memory = 8GB   │
 │ spark.executor.memoryOverhead=800MB
 └───────────────────────────────┘
                  │
                  │  (~300MB reserved)
                  ▼

        ┌────────────────────────┐
        │     Reserved Memory    │
        ├────────────────────────┤
        │      Spark Memory      │  <--- spark.sql.fraction = 0.6
        ├────────────────────────┤
        │      User Memory       │
        └────────────────────────┘
                  │
                  │    (dynamic)
                  ▼

        ┌────────────────────────┐
        │     Reserved Memory    │
        ├────────────────────────┤
        │  Storage Memory Pool   │  <--- spark.sql.storageFraction=0.5
        ├────────────────────────┤
        │  Execution Memory Pool │
        ├────────────────────────┤
        │       User Memory      │
        └────────────────────────┘

Size: (Executor Memory - Reserved Memory) × spark.sql.fraction

Default: ~60% of available memory (spark.sql.fraction = 0.8)

Components:

🟦 Storage Memory

3a. Storage Memory

👉 Short understanding:

This memory is mainly used for caching datasets or keeping broadcast variables. It grows whenever there is free execution memory, and shrinks when execution needs space. If memory is needed urgently, storage blocks get evicted first.

Initial Size: Spark Memory × spark.sql.storageFraction

Default: 50% of Spark Memory (spark.sql.storageFraction = 0.5)

Purpose:

Caching RDDs with .cache() or .persist()

Caching DataFrames and Datasets

Storing broadcast variables

Intermediate results from .checkpoint()

Eviction: Can be evicted when Execution Memory needs space

Spill Behavior: Cached data is either recomputed or read from disk based on storage level

🟥 Execution Memory

3b. Execution Memory

👉 Short understanding:

This is the “work memory” Spark uses during transformations like joins, aggregates and shuffles. Execution memory has higher priority, so it cannot be evicted. When full, Spark spills data to disk instead of crashing with OOM.

Initial Size: Spark Memory × (1 - spark.sql.storageFraction)

Default: 50% of Spark Memory

Purpose:

Shuffles: Hash tables and sort buffers during data shuffling

Joins: Hash tables for broadcast joins and sort-merge joins

Aggregations: Hash maps for groupBy operations and window functions

Sorting: Temporary space for orderBy operations

UDF Execution: Memory for complex user-defined functions

Eviction: Cannot be evicted (has higher priority than Storage)

Spill Behavior: When full, data spills to disk (controlled spilling)

(Controlled spilling is Spark's intelligent mechanism to handle situations when Execution Memory is full. Instead of crashing with an OutOfMemoryError, Spark gracefully moves some data from memory to disk, continues the operation, and reads the data back when needed.)

⭐ Practical Example: 1GB Executor Memory Breakdown

👉 Short understanding:

This example helps visualize real numbers. Reserved memory is fixed, and the rest gets partitioned between User vs Spark Memory. Then spark memory is again split into Storage vs Execution based on fractions.

Let's walk through a complete example with 1GB executor memory:

    Initial Memory Allocation

    Total Executor Memory: 1GB (1024MB)

    Step 1: Subtract Reserved Memory

├── Reserved Memory: 300MB (fixed)

└── Usable Memory: 724MB (1024MB - 300MB)

    Step 2: Split Usable Memory

├── User Memory: 145MB (724MB × 0.2)

└── Spark Memory: 579MB (724MB × 0.8)

    Step 3: Split Spark Memory

├── Storage Memory: 290MB (579MB × 0.5) - initially

└── Execution Memory: 289MB (579MB × 0.5) - initially

⭐ Important Dynamic Memory Allocation

👉 Short understanding:

Memory is not rigidly partitioned; Spark keeps it flexible. Execution memory has higher priority and may evict cached blocks. This dynamic behavior gives Spark better execution reliability under memory pressure.

Storage and Execution memory can borrow from each other

Storage can borrow from Execution: When execution memory is unused

Execution can borrow from Storage: When storage memory is unused

Eviction Policy: Storage memory can be evicted if execution needs space, but not vice versa

    spark.sql.fraction = 0.8 (default) // Fraction of Spark memory reserved for storage

    spark.sql.storageFraction = 0.5 (default) // Memory fraction that must remain after eviction

    spark.storage.storageFraction = 0.5 (default)

Overview

Tungsten is Apache Spark’s physical execution engine, introduced in Spark 1.4 as part of Project Tungsten. It focuses on optimizing CPU and memory efficiency, enabling Spark to run faster and with reduced GC overhead. Tungsten operates on the physical plan generated by the Catalyst optimizer and is the core engine that executes the plan using low-level system optimizations.

🔍 Quick Clarification:

✅ Code generation (aka whole-stage codegen) is part of the Tungsten physical execution engine—not Catalyst.

❌ Catalyst does not do code generation—it stops at generating the physical plan.

Key Capabilities of Tungsten

✅ Whole-Stage Code Generation

  Dynamically generates Java bytecode at runtime to process multiple operations in a single function.

  Eliminates function call overhead and intermediate row objects.

  Improves CPU cache locality.

✅ Binary Memory Layout (UnsafeRow)

  Uses a compact binary format to represent rows and columns.

  Reduces memory overhead and speeds up access.

  Enables efficient serialization/deserialization and sorting.

✅ Cache-Aware Computation

  Algorithms are optimized to operate efficiently within CPU cache sizes.

  Reduces memory shuffling and unnecessary access to slower memory.

✅ Manual Memory Management

  Spark gains control over how memory is allocated and released.

  Operates on both on-heap and off-heap memory depending on configuration.

✅ Tungsten operates with or without off-heap memory, but its performance is enhanced when off-heap is enabled.

  By default, Tungsten uses on-heap memory.

Spill buffers refer to temporary in-memory data buffers that are used during expensive operations like:

  Sorts

  Aggregations

  Shuffles

  Joins

When the executor's memory runs low, Spark spills these buffers to disk to avoid out-of-memory errors.

When you submit a SQL query or use the DataFrame API, Spark doesn't just run it blindly. Instead, it goes through several intelligent steps under the Catalyst Optimizer to analyze, optimize, and execute your logic efficiently.

Let's walk through each stage, combining functionality and real behavior:

🟫 1. SQL Query / DataFrame

You write: SELECT name FROM employees WHERE age > 30 or a similar DataFrame query.

This is the starting point — Spark simply takes your instructions as input.

🟩 2. Unresolved Logical Plan

What happens:

Spark creates an initial "blueprint" of your query — it knows the operations (select, filter), but hasn't confirmed if columns or tables exist.

'Project ['name]
+- 'Filter ('age > 30)
   +- 'UnresolvedRelation [employees]

It's called unresolved because:

  It hasn't looked up table schemas.

  It doesn't know if employees or name actually exist.

Purpose: Act as an abstract representation of what you want, without verification.

🟨 3. Logical Plan (After Analysis using Catalog)

What happens:

Spark checks the metadata catalog to resolve all columns, tables, and types.

It ensures everything exists and that operations like filtering and joining make sense.

Project [name#1]
+- Filter (age#2 > 30)
   +- Relation employees[id#0, name#1, age#2]

Purpose:

  Validates the query (semantic checks).

  Resolves all references.

  Applies type-checking.

This is where Spark throws errors if column/table names are wrong.

🔷 4. Optimized Logical Plan

What happens: Spark applies rule-based transformations to improve performance through a Rule-Based Optimizer (RBO):

Key Rules Applied:

  Filter pushdown - move WHERE clause as early as possible

  Constant folding - compute static expressions in advance

  Column pruning - drop unused columns

  Join reordering and elimination - optimize join order and remove unnecessary joins

  Boolean expression simplification - simplify AND/OR conditions

  Null propagation - handle null values efficiently

  Common subexpression elimination - avoid redundant calculations

Rule Engine:

  Rules are applied iteratively until no more improvements possible

  Each rule is a pattern-matching transformation

  Rules can be custom-defined and plugged into Catalyst

Purpose: Improve efficiency without altering the final result. Still doesn't specify how to execute the plan.

🟫 5. Physical Plans

What happens:

Spark now generates multiple execution strategies.

It considers how best to perform joins, aggregations, scans, etc. depending on data size and layout.

Examples:

  Should it use a broadcast join or a sort-merge join?

  Should it cache intermediate data?

Purpose: Translate logical operations into concrete steps that can run on a cluster.

🟦 6. Cost Model

What happens:

Spark estimates the cost of each physical plan:

  Based on I/O, CPU, memory usage, shuffles, and partition sizes.

  Uses table statistics and column histograms for better estimates.

It compares all options and chooses the lowest-cost plan.

Purpose: Select the most efficient execution path.

🟪 7. Selected Physical Plan

What happens: Spark now has a final physical plan ready to run.

Includes exact execution instructions:

  How to read data.

  When to shuffle.

  Partitioning schemes.

  Specific join strategies.

Purpose: Provide a complete, optimized execution roadmap for the engine.

🟥 8. Code Generation → RDDs

What happens:

Spark uses Tungsten engine to generate low-level JVM bytecode (Whole-Stage Code Generation).

The physical plan is turned into actual operations on RDDs.

These RDDs are then executed across the distributed cluster.

Purpose: Achieve high performance execution.

Error Handling

How Catalyst handles optimization failures and fallbacks:

Analysis Phase Errors:

  Unresolved references → Clear error messages with suggestions

  Type mismatches → Detailed type conflict information

  Schema validation failures → Points to exact column/table issues

Optimization Fallbacks:

  If code generation fails → Falls back to interpreted execution

  Complex expressions that can't be optimized → Uses original form

  Statistics missing → Uses default cost estimates

  Rule application failures → Skips problematic rules, continues with others

Runtime Adaptability:

  AQE monitors execution and re-optimizes if initial plan performs poorly

  Graceful degradation when optimizations don't work as expected

Partition Pruning

Skips reading unnecessary partitions based on filter conditions.

Example:

-- Table partitioned by year and month
SELECT * FROM sales WHERE year = 2024 AND month = 'January'

Only reads partitions matching year=2024/month=January

Avoids scanning other partition directories

Dramatically reduces I/O for large datasets

Constant Folding

Evaluates constant expressions at compile time instead of runtime.

Example:

SELECT price * (1 + 0.08),
       substr('Hello World', 1, 5),
       date_add('2024-01-01', 30)
FROM products

Optimized to:

SELECT price * 1.08,
       'Hello',
       '2024-01-31'
FROM products

1 + 0.08 becomes 1.08

String and date functions with constants get pre-computed

Eliminates redundant calculations per row

Predicate Pushdown

Moves filter conditions closer to the data source to reduce data movement.

Example:

SELECT name FROM (SELECT * FROM users JOIN orders ON users.id = orders.user_id)
WHERE age > 25

Optimized to:

SELECT name FROM (SELECT * FROM users WHERE age > 25) u
JOIN orders ON u.id = orders.user_id

Filter age > 25 applied before the expensive JOIN

Reduces rows processed in subsequent operations

Works with file formats (Parquet) and databases

Physical Plan Phase

What Happens: The physical planner takes the optimized logical plan and generates one or more physical execution strategies, then selects the best one based on cost estimates.

Key Transformations:

Operator Mapping:

Logical Join becomes SortMergeJoin, BroadcastHashJoin, or ShuffledHashJoin

Logical Aggregate becomes HashAggregate or SortAggregate

Logical Project becomes Project with codegen-ready expressions

Physical Strategies:

Cost-based selection: Chooses join algorithms based on table sizes and statistics

Partitioning decisions: Determines shuffle requirements and partition counts

Memory management: Allocates memory for operations like hash tables and sort buffers

Execution Planning:

Determines which operations can be pipelined together

Identifies shuffle boundaries (stage breaks)

Plans resource allocation and task distribution

Code Generation Prep:

Expressions get prepared for whole-stage code generation

Complex expression trees become Java code snippets

Operators get grouped into stages for codegen

Output: The result is an executable SparkPlan tree with concrete operators, memory allocations, and codegen-ready components that can be submitted to the cluster for execution.

Catalyst enables Tungsten optimizations during the physical planning phase.

How Catalyst Enables Tungsten

Code Generation Phase:

Catalyst's physical planner prepares expressions for Tungsten's code generation

Converts expression trees into codegen-ready formats

Enables whole-stage code generation by identifying fusible operators

Code generation (codegen) in Spark is a performance optimization that generates optimized Java bytecode at runtime instead of using interpreted execution.

Tungsten's Code Generation

What Tungsten Generates:

Java source code at runtime that gets compiled to bytecode

Whole-stage codegen - fuses multiple operators into single functions

Expression codegen - optimized evaluation of SQL expressions

Specific Integration Points:

Expression Evaluation:

Catalyst optimizes expressions logically

Passes optimized expressions to Tungsten for code generation

Tungsten generates efficient bytecode for those expressions

Operator Selection:

Catalyst chooses logical operators (Join, Aggregate)

Physical planner selects Tungsten-optimized implementations

Examples: UnsafeShuffleWriter, TungstenAggregate

Memory Management:

Catalyst plans memory usage patterns

Tungsten provides the actual off-heap memory management

Uses binary formats determined during physical planning

📌 File Formats in Spark – Complete Notes

(Parquet • ORC • Avro • JSON • CSV • Delta • Text)

🔶 1. CSV (Comma Separated Values)

📍 What it is

Plain text tabular format where values are separated using comma.

✔ Advantages

Human readable

Universally supported

Easy ingestion

✖ Disadvantages

No schema

No compression by default

Slow scanning

Heavy disk I/O

Spark impact

Slow query performance

High shuffle

Needs .option("header") frequently

Schema inference required

Use when

Interchange format

Small static files

System integration

🔶 2. JSON (JavaScript Object Notation)

📍 What it is

Semi-structured format storing data as key-value & nested objects.

✔ Advantages

Schemaless

Supports nested structures

Human readable

✖ Disadvantages

Larger size

Slow parsing

No indexing

Spark impact

slower scan

schema inference needed

expensive processing for nested fields

Use when

APIs

Logs

Streaming

🔶 3. Parquet (Columnar)

📍 What it is

Columnar storage format highly optimized for analytics.

✔ Advantages

Compression

Predicate pushdown

Column pruning

Fast read

Optimized for Spark

✖ Disadvantages

Insert slow

Update slow

Overhead for small rows

Spark benefits

fast scan

low shuffle

optimized for big data

best for transformation

Use when

Data lake

analytical workloads

🔶 4. ORC (Optimized Row Columnar)

📍 What

Similar to Parquet but optimized originally for Hive.

✔ Advantages

Best compression

Good query optimization in Hive

Indexing + dictionary encoding

✖ Disadvantages

Heavy metadata

Slightly slower in Spark than Parquet (Spark optimized for Parquet)

Spark impact

very good compression

better for Hive workloads

Use when

Hive heavy systems

Hadoop environment

🔶 5. Avro (Row Oriented)

📍 What

Row-based binary format with schema stored along with data.

✔ Advantages

Schema evolution

Row based writing

Compact

Good for messaging

✖ Disadvantages

Not optimized for analytics

Slow column scanning

Spark use

Kafka + Streaming

CDC data

schema evolution use cases

Use when

streaming pipelines

row-based messaging

🔶 6. Delta Lake

📍 What it is

Storage + transaction layer on top of parquet.

✔ Advantages

ACID transactions

Time travel

MERGE / UPDATE / DELETE

Streaming + batch unified

Schema evolution

✖ Disadvantages

Proprietary (open source, but Databricks led)

Slight storage overhead

Spark impact

Fast

Highly reliable

Supports ACID

Lakehouse recommended format

Use when

Data lakehouse

UPSERTS

Slowly changing dimensions

Streaming + batch

🔶 7. TEXT

✔ Advantages

simplest format

widely supported

✖ Disadvantages

no schema

no compression

poor performance

Spark use

quick testing

minimal ingestion

logs

⚡ Spark Performance Comparison

Format    Storage    Read           Compression    Analytics    Schema Evolution
CSV       poor       slow           none           bad          none
JSON      medium     slow           medium         bad          medium
Avro      medium     fast row       medium         medium       best
Parquet   best       fast column    best           best         good
ORC       best       fast           best           best         good
Delta     best
